Spindles Book WPS 27
£9.49.
Describes the design, construction and use of a variety of spindles that will be of interest to the amateur engineer. Milling, grinding and drilling spindles are covered along with a unique light gear cutting frame for clockmakers.
If you do not own a milling machine (and even if you do) what you can achieve in your workshop is greatly enhanced if you own a spindle or two for use with your lathe. Spindles come in many shapes and sizes, ranging from 19mm (0.75 in) to 57 mm (2.25 in) in diameter, depending on the uses envisaged for them. This book describes the design, construction and use of a variety of spindles that will be of interest to the amateur engineer. Milling, grinding and drilling spindles are covered along with a unique light gear-cutting frame for clockmakers.
The emphasis is on spindles that are easy to make and have as few parts as possible; all but one for example use sealed ball bearings (the exception uses tapered collar bearings and thus needs to have seals installed to protect the bearings.) The basic spindle described uses the same spindle nose as the Myford Super 7 lathe; this allows all chucks, plates, collets and closers designed for the lathe to be used with this spindle. It can also be modified for other lathe nose standards.
Harprit Singh Sandhu, BSME, MSCerE, is an American engineer and the founder of Rhino Robots Inc., where he was the chief designer of the ‘Rhino’ series of robots. In
his spare time he is a journeyman designer, machinist & woodworker, whose interest in clock making led him to design & build the spindles described in the book.
Originally published by Nexus Special Interests Ltd in
1997
Special Interest Model Books edition published in 2004
Specification:
210 x 148 mm
160 pages
15 black and white photographs
159 scale plans & line drawings
10 tables of data
ISBN 978 185486 149 8
Classification: Model Engineering/Lathes
Contents: Designing a Spindle; The Basic Spindle; Mounting a Spindle; A Smaller No.2 Morse Taper Spindle; Micro Spindle; 1 inch (25mm) Diameter Spindle; 1.25 inch (32mm) Diameter Spindle; Light, Tool-Post OD Grinding Spindle; Simple, No.1 Morse Taper Spindle; Vertical Spindle or Gear Cutting Frame; Spindle With Tapered Roller Bearings; Driving the Spindles; Notes on Using Spindles; Ancillary Information; SI Drawings; UK Equivalent Tables.
